Ref. frequency monitoring Fixed values
6 .. 12 kHz in steps from 1
kHz, 14 kHz, 16 kHz
+/- 20% +/-5% (measuring
tolerance)
Reference signal shape
Sine, triangle, no monitoring
40% shape deviation
Monitoring of quadrant count
signal / signal phase
Fixed value +/- 45°
