Monitoring of the supply voltage as per the nominal voltage selected:
Nominal voltage
Minimum voltage
Maximum voltage
5 VDC
4.4 VDC
5.6 VDC
8 VDC
7 VDC
9 VDC
10 VDC
8 VDC
12 VDC
12 VDC
10 VDC
14 VDC
24 VDC
20 VDC
29.5 VDC
