Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 156 of 201
Version: 25F
Process value (speed) => no change to the output status on reset in the alarm state
Time-based function => reset the output status, triggering if limit exceeded again
Safety instructions:
• For time-based functions, e.g. monitoring of the timing of complementary input signals,
the output status is reset and a state defined as erroneous only detected if the (time)
limit is exceeded again.
• To protect against incorrect usage, e.g. repeated triggering of the reset function to
bypass an alarm state, if necessary applicative measures must be taken in the PLC
programming.
