Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 2 of 201
Version: 25F
Installation instructions for basic devices in the series PSC1-C-100
- PSC1-C-100
- PSC1-C-100-MC
(1)
- PSC1-C-100-FBx
(2)
and their expansion modules
- PSC1-E-21-SDM1
- PSC1-E-22-SDM1-2
- PSC1-E-23-SDM2
- PSC1-E-24-SDM2-2
- PSC1-E-131-12DI-10DIO
- PSC1-E-133-12DI-6DIO-4RO
- PSC1-E-37-14DI-4DO-2RO-RIO
Options:
(1)
Memory Card to store the configuration, the program and the data; see chapter 3.7.4.2
(2)
For version see: “Optional universal communication interface"
Note:
The German version is the original version of the installation instructions
As of: 04/2016
Valid from firmware release Master 04-00-00-01
Central slave 04-00-00-01
Decentral slave 01-00-00-01
Subject to technical change without notice.
The content of this documentation has been prepared with the greatest possible care and corresponds
to the latest information available to us.
Nevertheless, we draw your attention to that fact that this document cannot always be updated
simultaneously
with the further technical development of our products.
Information and specifications may be changed at any time. Please obtain information on the
latest version at: www.schmersal.net.
K. A. Schmersal GmbH & Co. KG
Möddinghofe 30
D - 42279 Wuppertal
