PSC1-E-24-SDM2-2:
• 2 axes each with 2 encoders (so-called extended axes)
o Axis 1:
 Combination in table: Encoder 1: Column X1/X2, encoder 2: Column X3/X4
o Axis 2:
 Combination in table: Encoder 1: Column X1/X2, encoder 2: Column X3/X4
o Designation on device:
 Axis 1: Encoder 1: X1, encoder 2: X3
 Axis 2: Encoder 1: X2, encoder 2: X4
