schmersal PSC1 - Page 64

Installation manual
HB-37420-810-01-25F-EN PSC1-C-100 Installation manual - V2.2.docx Page 64 of 201
Version: 25F
Type
Encoder on
interface
X1/2
Type
Encoder on
interface
X3/4
Type
Encoder on
X 23
Input
(I04…I07)
Safe
speed
Safe
directio
n
Safe
position
Fault exclusion DC
1-channel
sub-system
2-
channel
sub-
system
dynamic
2-channel
sub-
system
non-
dynamic
(standstill
monitoring)
SIN/COS SSI NC X X X n.a. 99% 95-99%
SSI NC
2 x proximity
switch 90°
X X X n.a. 99% 90-95%
SSI SIN/COS NC X X X n.a. 99% 95-99%
SSI Resolver NC X X X n.a. 99% 95-99%
SSI SSI NC X X X n.a. 99% 90-95%
NC SIN/COS NC X X
Fault exclusion mech. shaft fracture, positive
locking encoder shaft connection required
90% 99% 90-95%
NC Resolver NC X X
Fault exclusion mech. shaft fracture, positive
locking encoder shaft connection required
90% 99% 90-95%
