Introduction
1–4 700-0042 R004
3 SHUTTLE wheel (outer wheel) • During playback, turning the SHUTTLE wheel clockwise speeds the play
forward from 1× to 2×, 4×, 6×, 8×, 16× and 32× the normal speed.
• During reverse playback, turning the
SHUTTLE wheel counter clockwise
speeds the play backward from 1×, 2×, 4×, 6×, 8×, 16× and 32× the
normal speed.
•When the
PAUSE button is pressed, turning the SHUTTLE wheel clockwise
reduces the play to a very slow forward rate.
•When the
PAUSE button is pressed, turning the SHUTTLE wheel counter
clockwise reduces the play to a very slow backward rate.
4
JOG wheel (inner wheel) • Used to change the values of menu items.
•When the
PAUSE button is pressed, turning the JOG wheel clockwise or
counter clockwise moves the image one at a time.
5 Infrared (IR) Remote Control
receiver
Used with the optional IR remote control pointed at the receiver.
6
POWER—DVR Power
indicator (green)
Illuminates when the DVR is powered up.
7
ALARM—Alarm Event
indicator (red)
Illuminates when an external alarm input has been initiated and remains
illuminated for the duration of the alarm.
8
LAN—Network indicator
(red)
Illuminates when connected to an active network.
9 DVR Buttons See Table 1-2.
10 Hard Drive Access indicator
(yellow)
Illuminates when the DVR is accessing the hard drive.
11 Hard Drive Power indicator
(green)
Illuminates when the hard drive has been properly inserted in the hard drive
tray, and the hard drive lock has been turned to the locked position.
12 USB Port Supports USB devices for:
• Copying video and audio information
• Exporting video clips (See “4.5.2. Using the ONE-TOUCH Download
option” on page 4–6.)
• Updating the DVR software
• Importing/exporting operating settings and profiles.
13
VIDEO OUT—Video Output
jack (yellow)
Used for:
• Live viewing
• Playback
• System configuration.
VIDEO OUT jack has the same function as the VIDEO OUT jack on the back of
the DVR. Only one device at a time can be connected to either jack.
Table 1-1
Front panel features
Item Feature Description
