SEON Explorer - Table 3-6 Estimated Recording Time in Hours with 40 GB Hard Drive

Configuring the DVR
700-0042 R004 3–11
If all the cameras are configured to record at the same resolution, frame rate and
picture quality, calculate the system recording capacity by dividing the value in
the table by the number of cameras. If the cameras are set to record at different
rates, contact Seon Design for assistance in calculating the recording capacity.
The EX4 DVR processes 4 different video inputs simultaneously — the frames
per second (FPS) is aggregate based on the sum of all the camera frame rates. In
other words, the recording times shown in Table 3-6 to Table 3-9 are independent
of how many cameras are connected to the DVR.
Important: The average image size is dependent on the scene content and the lighting
conditions. Your actual recording times may vary.
Table 3-6 Estimated recording time in hours with 40 GB hard drive
Frames per
second (FPS)
Picture Quality and
Resolution
2
360×240
4
360×240
6
360×240
2
720×240
4
720×240
6
720×240
2
720×480
4
720×480
6
720×480
30 88 68 42 55 42 26 35 24 11
20 1108055675234352411
15 12811269896945533919
10 146 125 80 98 80 52 73 55 26
7.5 158 119 87 106 80 63 79 56 30
6 175 145 97 109 97 67 79 67 31
5 197 164 123 141 123 90 110 82 45
4 237 190 159 190 136 105 119 95 50
3 341 256 205 256 205 147 172 128 69
2 496 374 280 373 280 225 281 187 112
1 849 640 424 638 427 343 428 318 212
