Specifications
A–4 700-0042 R004
A.4. Lock Box
A.5. Smart-Link™ Module
Main Enclosure 18 GA cold rolled steel (CRS)
Enclosure Brackets 18 GA CRS
Coating Outdoor polyester powder paint, black
Tray Slide Rails Industrial UHMW-PE
Door Lock Industrial cam lock, keyed alike. Different keying
available.
Dimensions (H × W ×D) 4.5 × 12 × 15" (114 × 305 × 380 mm)
Weight 8 lb (3.6 kg)
Power Harness Connector 4-pin Molex
Auxiliary Power Output
Connector
2-pin Molex
GPS Input Connector 4-pin Molex
Signals Connector 6-pin Molex
CAN bus Network Connector 4-pin Molex
Serial Port/GPS 9-pin DB9
Alarm Input Connector 8-pin Molex
Indicator Panel Connector 5-pin Molex
Speed Input Connector 3-pin Molex
Dimensions (H × W ×D) 5.875 × 3.25 × 0.875" (150 × 83 × 23 mm)
Weight 5.6 oz (160 g)
Material 14 GA aluminium, anodized black
