To connect to the back of the DVR:
1. Plug the 6-pin mini-DIN connector from each camera into the mating
connector on the back of the DVR. See Figure 2-4.
2. If an optional external microphone is being used, plug the power connection
into either
POWER 1 or POWER 2.
3. Plug the
RCA connector into the AUDIO IN 1 or AUDIO IN 2 jack. See “2.5.2.
Checking the Camera Cable Connections” on page 2–7 about disconnecting
the audio from a camera when using the external microphone.
4. Push the cables into the cable retainers on the back of the DVR brackets and
slide the DVR into the lock box.
2.5.2. Checking the Camera Cable Connections
The EX4 System uses an integrated mini-DIN connector for all of the camera
signals. The cable comes prewired into the camera, but if the cable is
disconnected, it can be easily reattached into the terminal blocks inside the
camera. See Figure 2-5. The cable colors for correct wiring to the terminals are
described in Table 2-1. For complete camera information, see the product insert
for the camera (for example, SA Series Wedge Camera Setup Guide document part
number 700-0004).
5 POWER 1
POWER 2
Auxiliary Power jacks (2.1 mm barrels)
6
VIDEO OUT Video output jack (yellow RCA style) for playback. (A video output jack is also
provided on the front panel of the DVR. However, only one device at a time can be
connected to either jack.)
7
AUDIO IN 1, 2
AUDIO OUT 1, 2
Audio input jacks (white RCA style) used with the two power output jacks for optional
remote microphones or IR modules
Audio output jacks (red RCA style) for playback
8
CAMERAS Four camera input connectors: 6-pin mini-DIN
9 FAN Fan with filter and removable cover keeps the unit cool. (For maintaining the filter, see
“5.1.3. Replacing the Fan Filter” on page 5–2.)
Item Feature Description
Important: Take care not to pinch or bind any cables when sliding the DVR into the
lock box.
