SEON Explorer - Table 3-14 GPS;SPEED Configuration Items

Configuring the DVR
3–20 700-0042 R004
To change a setting on the sub-menu:
1. Turn the
JOG wheel clockwise or counter clockwise to change the value.
2. Press the
LOCK > button to advance through the fields.
3. Press the
DISPLAY < button to move back through the fields.
The selected menu item is highlighted with a pale blue background.
4. Press the
CLEAR button to reload the default value into a field.
5. Exit the menu, press the
MENU button.
6. Repeat these steps to set the GPS Display, GPS Time, UTC Time Ref, Speed
Display, Speed Unit, Speed Pulse Count, and Calibrate Speed.
See Table 3-14.
Table 3-14 GPS/SPEED configuration items
Menu Item Description Values Default
GPS DISPLAY When GPS DISPLAY is ON, and a GPS receiver is connected to
the DVR, the latitude and longitude of the vehicle location
are displayed on the screen.
ON, OFF OFF
GPS
TIME A very accurate time source is embedded in the GPS
satellite signal. Setting the
GPS TIME to ON synchronizes the
DVR’S internal clock to the GPS satellite time. Because the
GPS satellites do not know where the GPS receiver is, the
GPS signal sends Universal time, or
UTC time (also known
as Universal Time Coordinated.)
ON, OFF OFF
UTC
TIME REF UTC is referenced to the atomic clock standard in
Greenwich, England. The
DVR location is a certain time
difference from
UTC time. For example, Eastern Standard
Time is –5 hours from
UTC time. Pacific Standard Time is –8
hours from
UTC time.
To use
GPS time, determine your time difference from UTC
time and enter this time into the
DVR. Use the time reference
to standard time. The
DVR keeps track of the Daylight
Saving Time changes internally (if auto daylight saving is
set to
ON).
–12 to + 12 in
one-hour
increments
–5
SPEED DISPLAY If speed is not being recorded, change the speed display
option to
OFF. This turns off the 0 on the display which
indicates zero speed.
If speed is being recorded, there are three sources that the
DVR can use to obtain vehicle speed:
• a pulse counting input
•a
GPS receiver
•vehicle
CAN network.
Set the speed display option to the desired input type. Note:
All of the speed input devices are optional. Contact your
sales representative at Seon Design to obtain the optimal
speed solution.
OFF, PULSE, GPS,
CAN
OFF
