3.2.4.2. Recording Capacity
The EX4 DVR uses
MPEG-4 video compression to extend the recording time on
the hard drive. The recording time varies, depending on the settings for frames per
second (speed), resolution, and picture quality.
The picture quality option lets you determine the amount a picture is compressed
versus the amount of memory the picture takes up on the hard drive. Table 3-5
shows the range for the picture quality settings where setting 1 is the standard
quality and setting 6 provides the highest picture quality. A higher picture quality
(6) means lower compression and therefore a higher memory requirement. A
lower picture quality (1) means higher compression and a lower memory
requirement.
Table 3-6 to Table 3-9 show the estimated recording time in hours for four
different hard drives, from 40 GB to 160 GB. The tables show the estimated
recording time in hours with one camera at the different settings for frames per
second (FPS), resolution, and picture quality.
RECORD DELAY-
ON TIME
Determines when the system starts up. The
Delay-On options uses Smart-Start™ which
protects the DVR from transients and
voltage swings during vehicle startup.
Note: After power up, the DVR may take up
to 80 seconds to start recording as it
performs a thorough self-test.
0, 15
SEC, 30 SEC, 1 MIN, 2 MIN,
3
MIN, 4 MIN, 5 MIN, 10 MIN,
15
MIN, 20 MIN, 30 MIN, 45 MIN,
and 60
MIN.
30
SEC
RECORD
DELAY-
OFF TIME
Enables the DVR to continue recording
after the driver has turned off the vehicle
ignition.
0 (disables Record Delay-off),
15
SEC, 30 SEC, 1 MIN, 2 MIN,
3
MIN, 4 MIN, 5 MIN, 10 MIN,
15
MIN, 20 MIN, 30 MIN, 45 MIN,
and 60
MIN.
30
SEC
POWER
DELAY-
OFF TIME
Keeps power and control signal to the DVR
only after the vehicle ignition is turned off
to allow a remote connection to access the
DVR’s video.
0
MIN to 255 MIN in five minute
increments.
5 minutes
Table 3-4
Record configuration items
Menu Item Description Values Default
Table 3-5
Picture quality settings
Setting Picture quality
1-
STD Standard
2
3
4
5
6-
HIGH Highest
