Configuring the DVR
700-0042 R004 3–9
CAMERA 1 to
CAMERA 4 SPEED
The camera speed can be set differently for
each camera.
Maximum aggregate speed of 30 FPS at
720×480 resolution across all four channels.
For example, 7.5 FPS for four cameras (7.5
FPS × 4 = 30 FPS)
10
FPS, 7.5 FPS, 6 FPS, 5 FPS, 4 FPS,
3
FPS, 2 FPS, 1 FPS, OFF
7.5 FPS
Maximum aggregate speed of 60 FPS at
720×240 resolution across all four channels.
For example, 15 FPS for four cameras (15
FPS × 4 = 60 FPS) at 720×240 resolution.
20
FPS, 15 FPS, 10 FPS, 7.5 FPS,
6
FPS, 5 FPS, 4 FPS, 3 FPS, 2 FPS,
1
FPS, OFF
Maximum aggregate speed of 120 FPS at
360×240 resolution across all four channels.
For example, 30 FPS for four cameras (30
FPS × 4 = 120 FPS) at 360×240 resolution.
30
FPS, 20 FPS, 15 FPS, 10 FPS,
7.5
FPS, 6 FPS, 5 FPS, 4 FPS, 3 FPS,
2
FPS, 1 FPS, OFF
CAMERA
1 to
CAMERA 4
QUALITY
The EX4 DVR uses MPEG-4 video
compression to extend the recording time on
the hard drive. The Quality option lets you
choose the amount a picture is compressed
versus the amount of memory the picture
takes up on the hard drive. A higher picture
quality (6) means lower compression and a
higher memory requirement. A lower
picture quality (1) means higher
compression.
Picture Quality
• 1 (Standard)
•2
•3
•4
•5
•6 (High)
4
RECORD AUDIO By turning Record Audio to OFF, no signal
is recorded from the audio inputs. This
feature is useful if no microphones are being
used as hard drive memory space is not used
to record unnecessary audio channels. At
slow record speeds, this can amount to a
considerable savings.
ON, OFF ON
REPEAT
RECORD By turning Repeat Record to ON, you can
choose to start recording again and
overwrite the information on the hard drive.
By turning Repeat Record to
OFF, you can
choose to stop recording and retain all the
information on the hard drive.
ON, OFF
Note: If Repeat Record is OFF and
the hard drive has been filled, the
DVR can be made to start recording
again by pressing the
REC button on
the DVR front panel for five
seconds.
ON
Table 3-4
Record configuration items
Menu Item Description Values Default
