Introduction
1–8 700-0042 R004
1.4. Lock Box
The lock box secures the DVR into a location on the bus and provides:
• A sliding rail system which allows for easy DVR installation and exchange.
• A slotted cable entry allows connectors to be inserted into the lock box after
installation.
• A removable, hinged locking door, rounded to prevent injury from sharp
edges.
• Mounting patterns that can accommodate installation flat on the floor,
vertically on the floor, or under a seat. (For installing the DVR under a seat,
use of the Underseat Mounting Bracket Kit is recommended. For installing
the DVR in a vertical mount, the Vertical Mounting Bracket Kit is
recommended. Contact your sales representative at Seon Design for more
information.)
1.5. Cables and Harnesses
The wiring connections to the EX4 System includes:
• A camera cable which comes with the camera, using a single connector for
ease of installation.
• A high-reliability power input harness for easy wiring of power and ignition
trigger.
• In-line fuses for the power and ignition lines for added protection.
• EX4 Plus: A driver’s indicator panel to allow easy event searching on the
DVR.
