Operating the DVR
700-0042 R004 4–3
Table 4-1
Using the DVR buttons
Button Description
POWER With the vehicle ignition turned OFF, and the DVR powered off, press the POWER button for 3
seconds to power up the DVR. Recording is not initiated.
With the vehicle ignition turned
OFF, and the DVR still powered up in the RECORD DELAY-OFF
interval, press the
POWER button for 5 seconds to power down the DVR immediately. (Record
Delay-Off Time enables the DVR to continue recording after the driver has turned off the
vehicle ignition. Record Delay-Off Time can be disabled or adjusted. See “3.2.4. Using the
Record Menu” on page 3–7.)
With the vehicle ignition turned
ON, press the POWER button for 5 seconds during the RECORD
DELAY-ON interval to power up the DVR and start recording. (Record Delay-On Time
determines when the EX4 System starts up. Record Delay-On Time can be adjusted. See “3.2.4.
Using the Record Menu” on page 3–7.)
FULL Press the FULL button in combination with one of the four camera buttons (CH1, CH2, CH3,
CH4,), and the DVR displays the selected camera in full screen display mode. If no camera is
plugged in, a blue screen is displayed.
Press the
MODE button to exit full screen display mode.
MODE Press the MODE button to change the viewing display.
ZOOM In full screen display mode, press the ZOOM button to zoom into the screen 2×.
Use the
ZOOM button with the JOG wheel to navigate the screen. See page 4–5.
Press the
ZOOM button again to exit zoom mode and return to full screen display mode.
DISPLAY <
<
• Press the DISPLAY < button to change the information shown on the display:
• All the information is shown.
• Removes the main title.
• Remove the camera title and DVR status display.
• Removes GPS location, speed, voltage, date and time.
• Restores all information.
While the DVR is recording in live mode, different information is displayed on the screen. See
Figure 3-1, “On-screen display during live viewing and recording” on page 3–2. Table 3-1 on
page 3–2 describes the items.
• Press the
DISPLAY < button to move to the previous field in menu mode when you are
configuring the DVR.
CLEAR When configuring the DVR, press the CLEAR button to restore the value in the field being
edited to the factory default value.
LOCK >
>
• Press the LOCK > button for three seconds in Live or Record mode to enable a One-Time
password option.
• Press the
LOCK > button to move to the next field when you are configuring the DVR.
