Specifications
A–2 700-0042 R004
A.1. EX4 DVR
Video Input/Output 75 Ohm NTSC video
Video Resolution 720 × 480, 720 × 240, 360 × 240 pixels
Video Compression MPEG-4
Hard Drive Style Single 2.5"
Hard Drive Size 40 GB, 80 GB, 120 GB, 160 GB
Hard Drive Removal Hot swappable, locking key-secured
Camera Input Connector 4 × 6-pin mini DIN connectors
Audio Input Level –8 dBm
Audio Output Level –6 dBm, 10 kΩ
Operating Temperature –4°F to 122°F (–20°C to 50°C)
Non-operating Temperature –22°F to 158°F (–30°C to 70°C)
Operating Humidity 90% relative humidity, non-condensing
Operating Voltage 8 to 18 VDC
Transient Protection 400 W
Temperature Protection Advanced Smart-Temp
Ingress Protection IP 53
Power Harness Connector 4-pin Molex®
Alarm Input Connector 2-pin Molex
Network Connector 8-pin RJ-45 Ethernet
Dimensions (H × W × D) 3.75 × 8.5 × 12.5" (95 × 216 × 318 mm)
Weight 7 lb (3.2 kg)
with SCT-LD brackets 8.5 lb (3.85 kg)
Power Circuit Fuse 5 A
Ignition Circuit Fuse 1 A
