MultiExact Gas Analyser Appendix
The following table shows the assignment for transducer 1. Each register provides
2 bytes of data.
Register
Name
Comments
101 – 102
Measurement
As seen on the measurement display.
Floating point number.
103 – 104
Filtered
measurement
Basic measurement, filtered.
Floating point number.
105 – 106
Pressure
compensated
measurement
Filtered and pressure compensated
measurement. Floating point number.
107 – 108
PMR
Primary measurement range.
109
Warming state
0 = not warming, 1 = warming.
110 – 112
Formula
Gas formula. ASCII text, 5 characters max,
terminated by a zero.
113 – 116
Units
Measurement units. ASCII text, 7 characters
max, terminated by a zero.
117
Auto val state
0 = idle, 1 = pre-warning, 2 = inerting,
3 = flushing, 4 = validating/calibrating.
118
Auto val gas
0 = low gas, 1 = high gas, 2 = sample gas.
119
Auto val finishing
0 = not finishing, 1 = finishing.
120
Auto val fail state
0 = auto validation OK,
1 = auto validation. failed
121
Active analogue
output range
0 = range 1, 1 = range 2.
122
Flow
Current flow through the sample line in
percent.
05410001A / Revision 6 107
