MultiExact Gas Analyser 9 – Fault finding
9.3 Diagnostics
The trace measurements have diagnostic capabilities. The displayed diagnostic
codes can be interrogated by the Servomex Service Team to determine the problem
with the transducers.
Diagnostics are only enabled for the trace O
2
, CO, CO
2
, N
2
O and CH
4
measurements. It will take up to 20 seconds for all the codes to be read for the
measurement and displayed.
If a transducer error or Tx maintenance status is displayed, and you have tried the
recommended actions and the fault still persists, use the following procedure to view
the diagnostics menu:
1. Select
Service
Diagnostics.
2. Take note of the displayed codes and
contact Servomex or your local
Servomex agent. This code can be
relayed to the Service Team who will
be able to determine the cause of the
fault.
Figure 100 – The diagnostics
screen
05410001A / Revision 6 91
