5 – Installation and set-up MultiExact Gas Analyser
5.2.7 Connect the electrical supply
Ensure that your external electrical supply outlet is isolated and
locked out before you connect the conductors in the electrical supply
cable.
Only use the power supply cord provided with the unit.
Ensure that the analyser is suitable for use with your electrical supply
voltage and frequency (refer to Section 2.3). If the analyser is not suitable,
the analyser may not operate correctly, or it may be damaged when you
operate it.
The analyser is supplied with an electrical supply cable, configured for your electrical
supply. Connect the electrical supply to the analyser as follows:
1. Fit the IEC plug on the end of the electrical supply cable provided to the
electrical supply socket on the rear of the analyser (Figure 2, item 8).
2. Route the cable towards your electrical supply outlet.
3. Connect the conductors at the free end of the electrical supply cable to your
electrical supply outlet.
4. Check the earth (ground) continuity between your electrical supply outlet earth
(ground) and the functional earth (ground) terminal on the rear of the analyser
(Figure 2, item 7).
5. If a local earth bonding is required the functional earth stud can be used (item 7,
Figure 2). The earthing cable must be kept to less than 3 metres to comply with
EMC standards. This does not replace the earth conductor on item 8 Figure 2
which must be connected.
34 05410001A / Revision 6
