MultiExact Gas Analyser 5 ā Installation and set-up
5 INSTALLATION AND SET-UP
The analyser must be installed by a suitably skilled and
competent person. The following procedure must be followed
to prevent a hazard.
The analyser is only suitable for installation in safe areas.
CAUTION
Do not install the analyser in a frame/rack or on a bench which is subject to
high levels of vibration or sudden jolts. If you do, sample measurements
may not be accurate, or the analyser may be damaged.
5.1 Mechanical installation
5.1.1 Bench mounting
Place the analyser on a firm level bench or other suitable solid worksurface.
The bench mounted analyser has four mounting feet. If required, the front two
mounting feet can be extended to raise the front of the analyser and so make the
analyser display easier to read and the soft keys easier to access.
With the front mounting feet extended, the fl
oats in the optional flowmeters
may not rotate, although the flow indications will be correct.
5.1.2 Panel mounting
The analyser must not be supported by the side mounting brackets alone.
You must provide an additional support under the base of the analyser
towards the rear of the enclosure as shown in Figure 9. If you do not, the
analyser may be damaged, or may fall and damage other equipment.
1. Refer to Figure 9. Prepare a cut-out (6) in a suitable panel (5).
2. Prepare a suitable base support (2) and secure it in your frame or cabinet.
3. If necessary (that is, if they are supplied separately), use the bolts and washers
supplied to fit the left-hand and right-hand mounting brackets (1, 4) to the
analyser (3).
05410001A / Revision 6 21
