MultiExact Gas Analyser 2 – Specification
2.4 Sample gas
☞
The sample gases must be non flammable, clean, non-
corrosive, free from oil
and condensates and compatible with the materials listed in Appendix A6.
Paramagnetic transducer (% O
2
)
Flow rate *
100 to 250 ml min
-1
Dew point
5 °C below ambient temperature (minimum)
Temperature
5 to 45 °C
Particulate size
< 2 µm (2 micron)
Zirconia transducer (trace O
2
)
Flow rate *
200 to 400 ml min
-1
Dew point
5 °C below ambient temperature (minimum)
Temperature
5 to 45 °C
Particulate size
< 2 µm (2 micron)
Infrared (GFX) transducer (trace)
Flow rate *
200 to 500 ml min
-1
Dew point
5 °C below ambient temperature (minimum)
Temperature
5 to 45 °C
Particulate size
< 2 µm (2 micron)
Thermal Conductivity transducer (%)
Flow rate *
100 to 200 ml min
-1
Dew point
5 °C below ambient temperature (minimum)
Temperature
5 to 45 °C
Particulate size
< 2 µm (2 micron)
*
The flow rates apply to flow-driven transducers only. On pressure-driven transducers, the
sample gas pressure must be in the range 14 to 56 kPa (2 to 8 psig).
