MultiExact Gas Analyser 5 – Installation and set-up
1. Select
Set up.
2. Select the required transducer and
alarm.
Figure 63 – The alarm set up screen
3. Select the required mode (none, low
or high), then press the soft
key.
Figure 64 – The alarm mode screen
4. Scroll up or down to edit the appropriate settings (using the method described
in Section 4.10):
• Latching (Section 5.11.2)
• Level (sets the gas concentration level at which the alarm is to trigger)
• Hysteresis (Section 5.11.3).
Each measurement has a 'Follow' option:
• If the 'Follow' option is set to 'No', the alarm will be inhibited during calibration.
• If the 'Follow' option is set to 'Yes', the alarm will not be inhibited during calibration.
1. Select
Follow.
2. Select the required alarm.
Figure 65 – The alarm follow screen
3. Select the correct option: "Yes" or
"No".
Figure 66 – The alarm follow
options screen
05410001A / Revision 6 61
