BEFORE
WEIGHING
MAINTENANCE
TROUBLESHOOTING
FOR YOUR
INFORMATION
USING THE
BALANCE
USING MORE CONVENIENTLY
107
V
Continued on next page
1
Press twice in the weighing mode.
This opens the main menu.
2
Select the target mode.
[TOOLS] [TARGT] [SET]
What is the current situation? What do you want to do?
Stability
Mark
Target Mode To Set / Update To Cancel
Lit
ON
Press and go to step 3.
Press and go to
step 4.
Unlit
OFF
Press and go to
step 3.
Go to step 4.
! !T!A!R!G!T
Check the presence or absence of the
stability mark.
9
COMPARATOR FUNCTION
Target Mode
The comparator function performs a comparison between the weight reading and a reference value or
target value and displays the status of this comparison.
Comparator Function
You can select and use either of these modes according to the environment of use and application.
Target mode
After setting a target value and a tolerance
range with respect to that target value,
excesses and decits in relation to the
target value are indicated by ,
and
(the comparator symbols).
(^ page 107)
Checkweighing mode
After setting the threshold values at the
upper and lower limits of the pass range,
when a sample is weighed a pass or fail
determination is indicated by ,
and
(the comparator symbols). An
out of range determination is indicated by all
comparator symbols OFF.
(^ page 109)
*
Before setting the comparator function
It can be used in combination with the application function mode (^ page 81).
If you are already using the application function mode, read "When the application function mode is set…"
(^ page 81).
The comparator function settings are retained even if the power is switched off.
