Shimadzu ATX-R Series User Manual

146
13
FOR YOUR INFORMATION

ATX-R /AT Y-R Series
Model Name ATX324R ATX224R ATX124R ATX84R ATY324R ATY224R ATY124R ATY64R
Weighing capacity 320 g 220 g 120 g 82 g 320 g 220 g 120 g 62 g
Minimum
indication
0.1 mg 0.1 mg 0.1 mg 0.1 mg 0.1 mg 0.1 mg 0.1 mg 0.1 mg
Range of external
weights for
calibration
95 - 320 g 95 - 220 g 45 - 120 g 45 - 82 g 95 - 320 g 95 - 220 g 45 - 120 g 45 - 62 g
Repeatability
(standard deviation)
≤ 0.15 mg ≤ 0.1 mg ≤ 0.15 mg ≤ 0.1 mg
Linearity
± 0.3 mg ± 0.2 mg ± 0.3 mg ± 0.2 mg
Response time
*1
Approx. 3.0 seconds
Operating
temperature and
humidity limits
5 - 40 °C 20~85%
*2
Tempe r at ur e
coefcient for
sensitivity
(10 - 30 °C)
± 2 ppm/°C
Pan size (mm)
Approx. f 91
*3
Main body
dimensions (mm)
Approx. 213 (W) × 356 (D) × 338 (H)
Main body weight
ATX-R: approx. 6.2 kg
ATY-R: approx. 6.0 kg
Display LCD
Rated electric
power supply
DC 12 V, 1 A
Pollution Degree 2
Overvoltage Category Category II
Installation Site device may only used indoors
AC adapter (primary) AC 100- 240 V, 320 mA 50/60 Hz
*4
I/O terminal RS232C(D-Sub 9P plug), USB device (Type B)
*1
The response time is a representative value.
*2
No condensation
*3
The size of the pan is the dimension of outer diameter.
*4
May differ depending on the AC adapter.
* The part numbers, specications, etc. indicated here are subject to change without notice.
Refer to our company website (https://www.shimadzu.com/an/balance/index.html) for the latest information.
Specications

Shimadzu ATX-R Series Specifications

General

Brand	Shimadzu
Model	ATX-R Series
Category	Scales
Language	English
