124
V
Connecting External Equipment
10
CONNECTION AND COMMUNICATION WITH PERIPHERAL DEVICES
Echo-back commands
A character string comprising N characters following an echo-back command "{" or "}" and
terminated by a delimiter is resent unchanged from the balance (provided unprocessed commands
do not remain in the balance's receive buffer, and N ≤ 30).
Example 5:
A B C D E F G 1 2 3 4 5
(C / R)
After receiving this command, the balance outputs A B C D E F G 1 2 3 4 5
(C/R).
When a printer is used in combination with the balance, this character string
can be printed by the printer (printing of any required character string).
*
To print with the printer
Only use upper case letters of the alphabet, numerals and some symbols (including the decimal
point and signs), and limit the string to within 15 characters.
Command list
Data output
Command Function
D01 Continuous output
*1
D02 Continuous output at stability
D03 Continuous output with stability information
D05 Single output
D06 Auto print setting
D07 Single output with stability information
D08 Single output at stability
D09 Cancel output
*1 When handshake is OFF, output at a cycle around 100 msec.
Key operation
Command Function
BREAK
Break key
Q
CAL Calibration key
TARE
Zero setting / taring key
T
PRINT Output key
*
Acceptance of commands
Depending on the status of the balance, even though a command is output it may not be
accepted, with the display of "COM ERR".
If "COM ERR" is displayed, try lowering the communication setting baud rate.
