USING THE
BALANCE
USING MORE CONVENIENTLY MAINTENANCE
TROUBLESHOOTING
FOR YOUR
INFORMATION
BEFORE
WEIGHING
21
V
Continued on next page
Back of the unit
RS232C USB DEVISE
DC IN connector
USB Device
Used to connect an AC
adapter for power supply.
Used to connect to a PC.
(^ P.117)
Used to connect to a printer
(e.g. EP-80 or EP-90).
(^ page 116)
RS232C connector
