Shimadzu ATX-R Series User Manual

24
V
Name and Function of Components
1
BEFORE WEIGHING
Display Name Description See:
Item number indication Shows the item number in the piece counting mode. Page 83
Inverse triangle symbol
Will be displayed during specic gravity measurement. Or if
displayed when the decimal place of the conversion coefcient
is changed to an arbitrary setting for each user, a value with no
decimal point can be input.
Page 46
Piece counting symbol Lit while the piece counting mode is in effect. Page 82
Specic percentage
weighing symbol
Lit when the specic percentage reference has been set for
percentage weighing.
Page 89
Percentage weighing
symbol
Lit during percentage weighing. Page 90
