Chapter 6
MSC800
78 Operating instructions | SICK 8011540/14B8/2019-06-06
Subject to change without notice
Commissioning and configuration
6.3.5 Saving, displaying, and printing current parameter set
In order to archive a parameter set, in addition to saving the project file, it is advisable to
print the file content.
1. In order to save the current parameter set, select the
SAVE AS menu item in the menu
bar under
PROJECT.
2. In the dialog window, enter a file name and confirm with
SAVE. The SOPAS-ET configure-
tion software saves the current settings in a “*.spr” configuration file.
3. In order to print out the current parameter set, in the menu bar under
PROJECT, select
the
PRINT/PRINT PREVIEW command. The SOPAS-ET configuration software displays a
preview of all parameter values in table form.
4. In the dialog window, in the toolbar at the top click
. The PRINT dialog window for the
configuration of the printer opens.
5. Edit the settings accordingly and confirm with OK. The current settings for the project
are printed in table form on several pages.
In order to save the current parameter set as a PDF, the
PRINT/SAVE AS PDF FILE command
is available in the menu bar under
PROJECT.
6.4 Default
The values of the default are permanently saved both in the MSC800 (ROM) and in the
database of the SOPAS-ET configuration software in the device-specific jar file.
A PC is not required for commissioning the MSC800 with the default settings.
Restoring MSC800 to the default
The SOPAS-ET configuration software is connected to the MSC800 online.
1. In order to completely discard the changes in the parameter set, in the menu bar under
MSC800, select the PARAMETERS/LOAD DEFAULT command. The SOPAS-ET configuration
software loads the default from the database and displays the parameter values in the
tabs.
2. Under
EXTRAS in the menu bar, select the LOG IN TO DEVICE command.
3. Under
USER LEVEL in the dialog window, in the list box, select the AUTHORIZED CUSTOMER
entry and enter the password “client” under PASSWORD. Confirm the dialog window
with OK.
4. Under
MSC800 in the menu bar, select the PARAMETERS/SAVE PERMANENTLY command.
The SOPAS-ET configuration software transfers the default into the permanent
parameter memory (Flash-PROM) of the MSC800.

TIP
Requirements

