SICK MSC800 User Manual

Chapter 10
MSC800
8011540/14B8/2019-06-06 Operating instructions | SICK 121
Subject to change without notice
Annex
10.3.3 Accessories: male connector covers for CLV490 / VMS4xx/5xx (CAN SENSOR network)
Part no. Description
1)
Connection
2021164 Male connector cover for CLV490 with parameter memory (EEPROM),
with 5-pin M12 female connector and 5-pin M12 male connector, IP 65
CLV490 on CAN SENSOR network
2035330 Male connector cover for CLV490 with parameter memory (EEPROM),
with 5-pin M12 female connector and 5-pin M12 male connector as well as
integrated
termination resistor 120 Ohm, IP 65
Bus closure on the last CLV490
2034152 Male connector cover set 2 for VMS410/510 (1 cover) with parameter
memory (EEPROM), with 5-pin M12 female connector and 5-pin M12 male
connector, IP 65
VMS410/510 on CAN SENSOR
network
2031365 Male connector cover set 6 for VMS420/520 (2 covers) with parameter
memory (EEPROM), with 5-pin M12 female connector and 5-pin M12 male
connector, IP 65
VMS420/520 on CAN SENSOR
network
1) Other male connector covers on request.
Tab. 56 Available accessories: male connector covers for CLV490 / VMS4xx/5xx (CAN SENSOR network)
10.3.4 Accessories: pre-wired cables for Ethernet connection (MSC800)
Part no. Description
1)
Length Connection
6026083 Patch cable, gray, shielded, twisted pair, with RJ-45 male connector (IP 20)
and RJ-45 male connector (IP 20), CAT5
3 m MSC800 via switch/hub
to Ethernet
6026084 Crossover cable, red, shielded, twisted pair, with RJ-45 male connector (IP 20)
and RJ-45 male connector (IP 20), CAT5
3 m MSC800 direct to
PC/Host
1) Other cables on request.
Tab. 57 Available accessories: pre-wired cables for Ethernet connection
10.3.5 Accessories: incremental encoder (MSC800)
Part no.
Description
2039455 Incremental encoder with friction gear, resolution 10 mm/clock, max. 100 kHz, supply voltage DC 10 ... 30 V,
operating temperature 0 ... +60
°C. With mounting bracket and material, connecting cable 10 m with 5-pin M12
female connector and open end. For operation with the ICR890 system and a MLG light grid
2039457 Incremental encoder with friction gear, resolution 0.2 mm/clock, max. 100 kHz, supply voltage DC 10 ... 30 V,
operating temperature 0 ... +60
°C. With mounting bracket and material, connecting cable 10 m with 5-pin M12
female connector and open end. For operation with the ICR890 system and a VMS4xx/5xx
2039456 Incremental encoder with friction gear, resolution 1 mm/clock, max. 100 kHz, supply voltage DC 10 ... 30 V, operating
temperature 0 ... +60
°C. With mounting bracket and material, connecting cable 10 m with 5-pin M12 female
connector and open end. Use is application-dependent (not for operation with VMS4xx/5xx)
Tab. 58 Available accessories: incremental encoder
