About these operating instructions
1.3 Target group
The target group for this document consists of people in the following roles:
Activities Target group
Mounting, electrical installation,
maintenance, and replacement of system
components
Qualified personnel, such as service technicians
or industrial electricians
Commissioning and configuration Qualified personnel, such as technicians or
Operation of the conveying system Personnel qualified in running and operating the
Tab. 1 Target group
1.4 Information depth
This document contains all information for the mounting, electrical installation, and
commissioning of the MSC800 on-site.
The configuration of the MSC800 for the application-specific reading situation and
operation for this purpose are carried out via the SOPAS-ET configuration software on a
Windows
TM
PC. In the SOPAS-ET configuration software, there is an online help system
available to support the configuration.
Further information on high-end CCD camera systems, volume measurement systems,
and bar code scanners is available from SICK AG, Identification & Measuring. Online at
www.sick.com.
1.5 Abbreviations used
Bitmap (pixel-oriented Windows format for saving photos)
Controller area network (fieldbus log based on the CAN bus)
Charge coupled device
Code reader V-principle
Depth of field
Electrically erasable programmable read-only memory (electrically erasable and
programmable nonvolatile memory)
File transfer protocol
Hypertext markup language (page description language used on the Internet)
Input
Image capture device (camera)
Image capture illumination
Image code reader (high-end CCD camera system)
Identification
Joint photographic expert group (pixel-oriented file format for saving photos with high
compression, compression procedure for Tiff formats)
Light emitting diode
Note
BMP
CAN
CCD
CLV
DOF
EEPROM
FTP
HTML
I
ICD
ICI
ICR
ID
JPEG
LED
