SICK MSC800 User Manual

Chapter 5
MSC800
60 Operating instructions | SICK 8011540/14B8/2019-06-06
Subject to change without notice
Electrical installation
5.4.5 Circuit breakers and fuses
The MSC800 is equipped with the following circuit breakers and fuses:
MSC800 type Fuse Fuse type Protected circuit Value/behavior
MSC800-1100
MSC800-2100
-F11 Circuit breaker, 1-pin Mains voltage AC 100 ... 264 V for
mains voltage module -G1
and Schuko plug socket -110X
10 A/trip characteristic
B, C, D
F1 to F6 Fine-wire fuse Supply voltage OUT F1 ... F5: 4 A/slow-acting
F6: 2 A/slow-acting
MSC800-2300 -F11 Circuit breaker, 1-pin Mains voltage AC 100 ... 264 V for
mains voltage modules -G1, -G2, and -
G3, and Schuko plug socket -110X
10 A/trip characteristic
B, C, D
-F111
-F113
-F115
Automatic circuit breaker,
each 1-pin
Supply voltage DC 24 V (OUT 2);
terminal -X120/11
Terminal -X120/13
Terminal -X120/15
20 A
F1 to F6 Fine-wire fuse Supply voltage DC 24 V (OUT 1) F1 ... F5: 4 A/slow-acting
F6: 2 A/slow-acting
MSC800-3400 -F11 Circuit breaker, 1-pin Mains voltage AC 100 ... 264 V
for mains voltage module -G1
10 A/trip characteristic
B, C, D
-F12 Circuit breaker, 1-pin Mains voltage AC 100 ... 264 V for
mains voltage module -G2
10 A/trip characteristic
B, C, D
-F111
-F113
-F115
Automatic circuit breaker,
each 1-pin
Supply voltage DC 24 V (OUT 1);
Terminal -X120/11
Terminal -X120/13
Terminal -X120/15
10 A
-F121
-F123
-F125
Automatic circuit breaker,
each 1-pin
Supply voltage DC 24 V (OUT 2);
Terminal -X120/21
Terminal -X120/23
Terminal -X120/25
10 A
F1 Fine-wire fuse Supply voltage OUT 1 on
thermal circuit breaker 2 /fans 1 and 2
4 A/slow-acting
MSC800-3600 -F11 Circuit breaker, 1-pin Mains voltage AC 100 ... 264 V for
Power supply unit modules -G1 and -G2
10 A/trip characteristic
B, C, D
-F12 Circuit breaker, 1-pin Mains voltage AC 100 ... 264 V for
Power supply unit modules -G3 and -G4
10 A/trip characteristic
B, C, D
-F13 Circuit breaker, 1-pin Mains voltage AC 100 ... 264 V for
Power supply unit modules -G5 and -G6
10 A/trip characteristic
B, C, D
-F111
-F113
-F115
Automatic circuit breaker,
each 1-pin
Supply voltage DC 24 V (OUT 1);
Terminal -X120/11
Terminal -X120/13
Terminal -X120/15
10 A
-F121
-F123
-F125
Automatic circuit breaker,
each 1-pin
Supply voltage DC 24 V (OUT 2);
Terminal -X120/21
Terminal -X120/23
Terminal -X120/25
10 A
-F131
-F133
-F135
Automatic circuit breaker,
each 1-pin
Supply voltage DC 24 V (OUT 3);
Terminal -X120/31
Terminal -X120/33
Terminal -X120/35
10 A
F1 Fine-wire fuse Supply voltage OUT 1 on
thermal circuit breaker 2 / fans 1 and 2
4 A/slow-acting
Tab. 33 Circuit breakers and fuses
