Siecor 5000 Series - Definition of X, Y, Z Directions; Overview of Modular Units; Modular Units

M90 Fusion Splicer 1-4 Operating Instructions
Getting to Know the M90 Fusion Splicer Issue 02/97
Definition of
X, Y, Z
directions
Y
X
X
Z
Z
Y
Fiber Direction
Overview of Modular Units
Modular
units
The splicer is made up of service-friendly modular units.
M=23%
5
1
1
2
3
4
Overview of the Fusion Splicer Modules
1 Power supply
2 Fusion unit
3 Monitor and
control panel
4 Input/output
5 Case lid
