M90 Fusion Splicer 7-26 Operating Instructions
Troubleshooting and Care/Maintenance Issue 02/97
Changing the
AC power fuse
Warning
This work may only be performed by appropriately qualified personnel.
Take a new fuse and the size 3 screwdriver from the tool bag.
Danger
Switch off the splicer! Disconnect the power plug!
- Open the top panel as described in this section.
- Pull out the faulty fuse (see figure below).
- Fit the new fuse (1).
Danger
Only use the original fuses specified.
AC power fuse: medium time-lag 2.5 A.
AC Power Fuse
Close the top panel and tighten the bolts securely.
