Operating Instructions 3-3 M90 Fusion Splicer
Issue 02/97 Parameters and Programs
Default parame-
ters
Cleaning current:
Cleaning time:
14.5 mA
0.1 s
Single-Mode Fibers Multimode Fibers
Z-gap: 7.0 µm 7.0 µm
Autofeed: 5.0 µm 5.0 µm
Prefusion current: 15 mA 13.5 mA
Prefusion time: 0.25 s 0.5 s
Fusion current: 15 mA 14 mA
Fusion time: 1.2 s 5 s
or min. fusion time: 0.8 s -
max. fusion time: 10.0 s -
Tensile test: on on
LID system: internal internal
The default parameters for the attenuation splice are given in section 5.
Setting the lan-
guage
To select the language, move to the first line using the
button and press the but-
ton as often as necessary until the required language flashes. The selected language is
activated after confirming with the
button.
Abbrev. Language Abbrev. Language
D German PL Polish
GB English CZ Czech
F French GUS Russian
E Spanish Chinese
NL Dutch IRA Farsi
H Hungarian
The available languages may differ depending on the software version installed.
