Siecor 5000 Series - Fixed Parameters (LID); Manual; Variable Fusion Curve; Manual

Operating Instructions 4-17 M90 Fusion Splicer
Issue 02/97 Splicing
Fixed Parameters (LID) / Manual
Variable Fusion Curve / Manual
Fully automatic
Automatic
Semi automatic
Manual
or
or
or
or
Clean fibers?
Searching fibers?
Align fibers manually?
Automatic XYZ and
fuse?
Automatic XY?
Left fiber slide forwards/
backwards ####
Right fiber slide forwards/
backwards ####
X axis: ####
Y axis: ####
Fusing?
Automatic XYZ, clean,
fuse?
