Siecor 5000 Series - General; Button Functions; Selecting the Fusion Program; Fusion Program Groups

Operating Instructions 4-3 M90 Fusion Splicer
Issue 02/97 Splicing
General
Note
Ensure that all preparations for splicing have been performed correctly and completely.
Otherwise turn to section 2 and perform the necessary preparations on the splicer and
optical fibers.
Button functions
Switch to the Parameter menu (e.g. for program selection) or return to the last pro-
gram step in the fusion program
Change the displayed parameters
Change the displayed parameters
Reply "Yes" to displayed question. The relevant operation is initiated.
Reply "No" to displayed question or abort the current operation. Return to previous
operation.
Reply "No" to displayed question or skip indicated operation.
Selecting the Fusion Program
The various splicing programs and parameters are listed in section 3.
With this information available to you, you should now be able to specify and activate
the required splicing program.
If you have not already done so, activate the required program in the Parameter menu
and return with the
button.
Fusion program
groups
The splicer provides the following program groups:
1. Automatic fusion time for single-mode fibers
2. Fixed parameters (LID) for single-mode and multimode fibers
3. Fixed parameters(video) for single-mode and multimode fibers
4. Variable fusion curve for single-mode and multimode fibers
5. Attenuation splice for single-mode fibers
Each of these 5 program groups has 5 parameter sets (programs) whose parameters
can be set individually.
