M90 Fusion Splicer 1-14 Operating Instructions
Getting to Know the M90 Fusion Splicer Issue 02/97
Technical Specifications
Fiber require-
ments
Single- and multimode fibers
with 125-µm glass diameter
and a coating diameter of 250
to 900 µm
Positioning In X/Y axis through high-
resolution piezo-ceramic posi-
tioners with 120-µm travel
(resol. < 0.1 µm)
In Z-axis through two stepping
motors each with feed travel
of 3 mm plus high-resolution
piezo-ceramic positioner with
30-µm travel (resolution < 0.1
µm)
Video system High-resolution video system
with 2-axis imaging system
4" LCD color monitor
75x magnification
Operating temp. - 5 ° C to + 45 ° C
Storage temp. - 20 ° C to + 70 ° C
AC power supply 95 - 260 V through automatic
voltage range selection
50 - 60 Hz, max 100 VA
Microprocessor 80C537 (Siemens)
Connecting jacks For heatshrink oven and
working light
Battery Lead-acid battery as special
accessory:
12 V, 6.5 Ah for appr. 3 - 4 h
operation per charge cycle
(splicer only).
Charge time: 3 hours after
complete discharge, exhaus-
tive discharge protection
External 12-V
supply
12 - 14.5 V, max. 5 A, pro-
tected against polarity rever-
sal
Data memory For 1000 splice values
Data output RS 232 interface with variable
baud rate
Monitor output 75 Ω, for external monitor of
CCIR standard
Connection: Cinch plug
Cable length: max. 10 m
Light arc AC voltage, fusion current
adjustable from 10 - 20 mA
LID transmitter LED, wavelength 1300 nm,
temperature compensated
LID receiver Phase-sensitive
Attenuation splice 1 to 10 dB (0.1 dB step width)
Tensile tester Tensile load 2.5 ± 0.5 N
Realtime clock Time and date display, battery
backup
Splicer:
Weight
(without battery)
Outside dimen-
sions
( L x W x H )
14.5 kg
420 x 320 x 180 mm
Battery:
Weight
Outside dimen-
sions
( L x W x H )
2.7 kg
160 x 110 x 70 mm
Splice time Typically < 1 min
