Operating Instructions 2-11 M90 Fusion Splicer
Issue 02/97 Preparations
Fiber guide
250 µm
Insert the fiber into the fiber guide so that the coating stripping edge lies within the
marking (A) (see figure).
Inserting the Fiber into the Fiber Guide for 250
m
Closing the
flaps
- Close the flap of the fiber holder.
- Insert the second fiber in the same way (procedure as described from "Opening the
flaps" onwards).
- Now close the electrode flap.
Note
To prevent the optical fibers becoming dirty, perform steps "Cleaning", "Stripping" and
"Inserting into the Splicer" one immediately after the other.
