Connections 05.05
6-70 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Options:
Terminal expansion CUD2
Terminal type
: Plug-in terminal (screw-type)
Max. connection cross-section 1.5mm
2
Motor interface (see also function diagrams, Section 8, sheets G185 and G186)
Module C98043-A7006 CUD2
Function Terminal
X164
Connection values/Remarks
Motor temperature
(temperature sensor input)
204
205
Sensor acc. to P490 index 2
The cable to the temperature sensor on the motor must
be shielded and connected to ground at both ends.
Module C98043-A7006 CUD2
Function Terminal
X161
Connection values/Remarks
Supply for digital inputs
(output)
210 24V DC, short circuit proof with respect to internal
ground
max. load 200mA (terminals 34, 44, and 210
combined),
Overload response: Error signal F018
Warning signal A018
Binary input
Binary input
Binary input
Binary input
211
212
213
214
H signal: +13V to +33V
L signal: – 33V to +3V or terminal open
Input resistance = 2.8k
Ω
Ground for binary inputs
Ground for binary inputs
M
215
216
217
can be isolated from internal ground
(open wire jumper between terminals
216 and 217)
Analog inputs (see also Section 8, sheet G114)
Module C98043-A7006 CUD2
Function Terminal
X164
Connection values/Remarks
Select input analog 2
Ground analog
8
9
Select input analog 3
Ground analog
10
11
±10V, 52k
Ω
Resolution: ±10bit
Common mode suppression: ±15V
Analog outputs (see also Section 8, sheet G116)
Module C98043-A7006 CUD2
Function Terminal
X164
Connection values/Remarks
Select output analog 3
Ground analog M
18
19
Select output analog 4
Ground analog M
20
21
0
. . . ±10V, max. 2mA
Short-circuit-proof
Resolution ±11bit
