Start-Up 05.05
7-58 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Bits 12 to 15 contain the request identifier or the associated response identifier as shown in the
following list:
Response identifier Request
identifier
Meaning
positive negative
0 No request 0
1 Request parameter value (word or double word) 1 or 2
2 Modify parameter value (word) 1
3 Modify parameter value (double word) 2
4 Request descriptive element 3
5 Reserved -
6 Request parameter value (array) (word or double word) 4 or 5
7 Modify parameter value (array - word) 4
8 Modify parameter value (array-double word) 5
9 Request number of array elements 6
10 Reserved -
11 Modify parameter value (array-double word) and store in EEPROM 5
12 Modify parameter value (array-word) and store in EEPROM 4
13 Modify parameter value (double word) and store in EEPROM 2
14 Modify parameter value (word) and store in EEPROM 1
15 Request text 15
7 or 8
If the drive has been unable to process the request, it does not return the associated response
identifier, but error identifier 7 (or 8) instead.
In this case, an error code defining the error in more detail as shown in the following list is returned
as a parameter value:
Error code Meaning
0 Illegal parameter number (PNU) No PNU specified
1 Parameter value cannot be modified Visualization parameter
2 Lower or upper value limit violated
3 Faulty subindex
4 Parameter is not indexed (no array)
5 Incorrect data type
6 Parameter value can only be reset
7 Descriptive element cannot be modified
8 PPO Write (acc. to "Information Report") is not available
9 Parameter description is not available
10 Incorrect access level
11 No parameterizing enable (P927)
12 Keyword missing Key parameter P051 incorrectly set
13 Text cannot be read cyclically
15 No text
16 PPO Write missing
17 Incorrect operating state
19 Value cannot be read cyclically
101 Parameter number currently deactivated
102 Channel not wide enough
