05.05 Start-Up
SIEMENS AG 6RX1700-0AD76 7-59
SIMOREG DC Master Operating Instructions
Error code Meaning
103 PKW number incorrect Applies only to serial interfaces
104 Illegal parameter value Applies to BiCo selection parameters
105 Indexed parameter
106 Request not implemented in drive
107 Text cannot be modified
108 Incorrect number of parameter values Applies to "Change all indices" request
The index IND contains a "0" for non-indexed parameters; a 8-bit long index value is entered (in
the low-order byte) for indexed parameters.
Bit 15 (Page Select bit) has a special function. This is used to identify parameter numbers higher
than 1999 (see above for details of recoding parameter numbers).
Exception: In the case of cyclical PROFIBUS services, the L and H byte sequence is reversed (see
"Start-up of PROFIBUS boards").
Header
Trailer
Index
IND
Bit
15
Parameter value
PWE
Parameter identifier
PKE
Index, L byteIndex, H byte
An index value of 255 means that the request applies to all indices of the relevant parameter. In the
case of a modification request, the parameter values for all indices of the parameter must be
transferred. Conversely, the drive supplies all index values in its response to a read request.
The parameter value PWE is treated like a double word (PWE1 and PWE2). The high word is set
to 0 when a single word is transferred.
Header
Trailer
Index
IND
PWE2PWE1
Parameter value
PWE
Parameter identifier
PKE
