Siemens 6RA7086-6KS22

Function diagrams 05.05
8-8 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Sheet G110 Binary inputs terminals 36 to 39
87564321
P24_S
34
24V
5V
39
M
1
1
24V
5V
36
M
M
35
24V
5V
37
M
1
24V
5V
38
M
1
39 38 37 36
40
414243
211212213214
- G110 -
X171
E- Stop
CUD1
[G130.1] [G180.2] [G145.2]
B0016 B0017 B0011 B0010 B0012 B0013 B0014 B0015
r010
K0020
Binary inputs (1)
Switch-on/Shutdown (to Sheet "Crawling setpoint / Terminal 37") Enable operation (to sheet "Control word 1")
Display of terminal states on 7-segment display
IRES (to sheet "Pulse encoder evaluation")
