05.05 Description
Siemens AG 6RX1700-0AD76 3-5
SIMOREG DC Master Operating Instructions
Load cycles
Tu DC I DC II DC III DC IV
US rating
Tu=45°C
continuous 15min
100%
60sec
150%
15min
100%
120 sec
150%
15min
100%
10sec
200%
15min
100%
60sec
150%
Recommended
SIMOREG DC Master
° C A A A A A A A A A
690V, 1Q
6RA7086-6KS22 40 720 553.1 829.7 527.9 791.9 515.8 1031.6 525.9 788.9
6RA7088-6KS22 40 950 700.1 1050.2 677.1 1015.7 624.4 1248.8 668.1 1002.2
6RA7093-4KS22 40 1500 1156.9 1735.4 1118.2 1677.3 1047.0 2094.0 1101.9 1652.9
6RA7095-4KS22 40 2000 1589.3 2384.0 1522.2 2283.3 1505.5 3011.0 1503.9 2255.9
6RA7097-4KS22 40 2600 1992.7 2989.1 1906.3 2859.4 1887.2 3774.4 1876.9 2815.3
830V, 1Q
6RA7088-6LS22 40 900 663.8 995.7 642.0 963.0 592.1 1184.2 633.5 950.3
6RA7093-4LS22 40 1500 1156.9 1735.4 1118.2 1677.3 1047.0 2094.0 1101.9 1652.9
6RA7095-4LS22 40 1900 1485.4 2228.1 1421.6 2132.4 1396.9 2793.8 1414.2 2121.3
950V, 1Q
6RA7096-4MS22 40 2200 1674.3 2511.4 1603.3 2404.9 1570.7 3141.4 1588.1 2382.1
3.4.1.2 Load cycles for 4Q applications
Load cycles
Tu DC I DC II DC III DC IV
US rating
Tu=45°C
continuous 15min
100%
60sec
150%
15min
100%
120 sec
150%
15min
100%
10sec
200%
15min
100%
60sec
150%
Recommended
SIMOREG DC Master
° C A A A A A A A A A
400V, 4Q
6RA7013-6DV62 45 15 13.9 20.9 13.5 20.3 12.6 25.2 13.9 20.9
6RA7018-6DV62 45 30 24.9 37.4 24.2 36.3 22.4 44.8 24.9 37.4
6RA7025-6DV62 45 60 53.1 79.7 51.8 77.7 47.2 94.4 53.1 79.7
6RA7028-6DV62 45 90 78.2 117.3 76.0 114.0 72.2 144.4 78.2 117.3
6RA7031-6DV62 45 125 106.1 159.2 103.6 155.4 95.4 190.8 106.1 159.2
6RA7075-6DV62 40 210 164.9 247.4 161.4 242.1 136.5 273.0 157.5 236.3
6RA7078-6DV62 40 280 226.8 340.2 219.3 329.0 201.0 402.0 215.8 323.7
6RA7081-6DV62 40 400 300.1 450.2 292.4 438.6 247.4 494.8 285.5 428.3
6RA7085-6DV62 40 600 470.8 706.2 453.9 680.9 410.4 820.8 450.1 675.2
6RA7087-6DV62 40 850 658.3 987.5 634.2 951.3 579.6 1159.2 626.4 939.6
6RA7091-6DV62 40 1200 884.1 1326.2 857.5 1286.3 768.8 1537.6 842.3 1263.5
6RA7093-4DV62 40 1600 1255.5 1883.3 1213.1 1819.7 1139.9 2279.8 1190.1 1785.2
6RA7095-4DV62 40 2000 1477.7 2216.6 1435.3 2153.0 1326.7 2653.4 1404.6 2106.9
6RA7098-4DV62 40 3000 2288.0 3432.0 2189.1 3283.6 2164.0 4328.0 2178.6 3267.9
