Description 05.05
3-6 Siemens AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
Load cycles
Tu DC I DC II DC III DC IV
US rating
Tu=45°C
continuous 15min
100%
60sec
150%
15min
100%
120 sec
150%
15min
100%
10sec
200%
15min
100%
60sec
150%
Recommended
SIMOREG DC Master
° C A A A A A A A A A
460V, 4Q
6RA7018-6FV62 45 30 24.9 37.4 24.2 36.3 22.4 44.8 15.0 22.5
6RA7025-6FV62 45 60 53.1 79.7 51.8 77.7 47.2 94.4 30.0 45.0
6RA7028-6FV62 45 90 78.2 117.3 76.0 114.0 72.2 144.4 60.0 90.0
6RA7031-6FV62 45 125 106.1 159.2 103.6 155.4 95.4 190.8 100.0 150.0
6RA7075-6FV62 40 210 164.9 247.4 161.4 242.1 136.5 273.0 140.0 210.0
6RA7078-6FV62 40 280 226.8 340.2 219.3 329.0 201.0 402.0 210.0 315.0
6RA7082-6FV62 40 450 320.6 480.9 311.2 466.8 274.3 548.6 255.0 382.5
6RA7085-6FV62 40 600 470.8 706.2 453.9 680.9 410.4 820.8 430.0 645.0
6RA7087-6FV62 40 850 658.3 987.5 634.2 951.3 579.6 1159.2 510.0 765.0
6RA7091-6FV62 40 1200 884.1 1326.2 857.5 1286.3 768.8 1537.6 850.0 1275.0
575V, 4Q
6RA7025-6GV62 45 60 53.1 79.7 51.8 77.7 47.2 94.4 53.1 79.7
6RA7031-6GV62 45 125 106.1 159.2 103.6 155.4 95.4 190.8 106.1 159.2
6RA7075-6GV62 40 210 164.9 247.4 161.4 242.1 136.5 273.0 157.5 236.3
6RA7081-6GV62 40 400 300.1 450.2 292.4 438.6 247.4 494.8 285.5 428.3
6RA7085-6GV62 40 600 470.8 706.2 453.9 680.9 410.4 820.8 450.1 675.2
6RA7087-6GV62 40 850 658.3 987.5 634.2 951.3 579.6 1159.2 626.4 939.6
6RA7090-6GV62 40 1100 804.7 1207.1 782.6 1173.9 689.6 1379.2 766.8 1150.2
6RA7093-4GV62 40 1600 1255.5 1883.3 1213.1 1819.7 1139.9 2279.8 1190.1 1785.2
6RA7095-4GV62 40 2000 1663.0 2494.5 1591.2 2386.8 1568.4 3136.8 1569.5 2354.3
6RA7096-4GV62 40 2200 1779.6 2669.4 1699.9 2549.9 1697.2 3394.4 1678.0 2517.0
6RA7097-4GV62 40 2800 2136.6 3204.9 2044.1 3066.1 2022.1 4044.2 2024.0 3036.0
690V, 4Q
6RA7086-6KV62 40 760 598.7 898.1 575.4 863.1 532.9 1065.8 569.3 854.0
6RA7090-6KV62 40 1000 737.3 1106.0 715.2 1072.8 639.5 1279.0 702.3 1053.5
6RA7093-4KV62 40 1500 1171.6 1757.4 1140.1 1710.2 1036.6 2073.2 1116.2 1674.3
6RA7095-4KV62 40 2000 1477.7 2216.6 1435.3 2153.0 1326.7 2653.4 1404.6 2106.9
6RA7097-4KV62 40 2600 1992.7 2989.1 1906.3 2859.4 1887.2 3774.4 1876.9 2815.3
830V, 4Q
6RA7088-6LV62 40 950 700.8 1051.2 679.8 1019.7 607.8 1215.6 667.6 1001.4
6RA7093-4LV62 40 1500 1171.6 1757.4 1140.1 1710.2 1036.6 2073.2 1116.2 1674.3
6RA7095-4LV62 40 1900 1485.4 2228.1 1421.6 2132.4 1396.9 2793.8 1414.2 2121.3
950V, 4Q
6RA7096-4MV62 40 2200 1674.3 2511.4 1603.3 2404.9 1570.7 3141.4 1588.1 2382.1
