SIMOREG DC Master Operating Instructions
2)1)
Rx Tx
+
56575859
--
++
6RA70
Rx Tx
+
56
57
58
59
-
-
+
+
6RA70
Rx Tx
+
56
575859
-
-
++
6RA70
Rx Tx
+
56
57
58
59
-
-
++
6RA70
Peer link type "Parallel connection"
Up to 31 drives receive identical setpoints from drive 1
1)
The interface cable shields must be connected directly on the converter with the lowest possible
impedance to converter or cubicle earth (e.g. via a clamp).
2)
Twisted cable, e.g. LIYCY 2x0.5 sqmm; with longer cables, an equipotential bonding conductor
must be used to ensure that the difference in frame potentials between nodes stays below 7V.
Drive 1 Drive 2
(
Bus terminating
resistors deactivated
)
Drive 3
(
Bus terminating
resistors deactivated
)
Drive n
(n <= 32)
(
Bus terminating
resistors activated
)
2)1)
Rx
+
56
575859
--
++
6RA70
Rx
+
56
57
58
59
-
+
6RA70
Rx
+
56
575859
-
+
+
6RA70
Rx
+
56
57
58
59
-
++
6RA70
1
0
Tx
-
+
1
0
Tx
1
0
Tx
1
0
Tx
-
-
Peer link type "Bus connection"
Up to 31 drives receive identical setpoints from one drive. The setpoint source drive is selected with
"Enable transmit" = 1. "Enable transmit" = 0 must be preset for all other drives.
1)
The interface cable sheilds must be connected directly on the converter with the lowest possible
impedance to converter or or cubicle earth (e.g. via a clamp)
.
2)
Twisted cable, e.g. LIYCY 2x0.5 sqmm; with longer cables, an equipotential bonding conductor
must be used to ensure that the difference in frame potentials between nodes stays below 7V.
Bus terminating
resistors deactivated
Bus terminating
resistors deactivated
Bus terminating
resistors activated
Transm.
data
Enable
transmit=1
Bus terminating
resistors activated
Enable
transmit=0
Enable
transmit=0
Enable
transmit=0
