Siemens 6RA7086-6KS22

Function descriptions 05.05
9-46 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
6RA7078-6DS22 and 6RA7078-6FS22
6RA7078-6DV62 and 6RA7078-6FV62
Tp (s) Tp (s) Tp (s) Tp (s) Tp (s) Tp (s)
Ig (%) X=1.8 X=1.5 X=1.4 X=1.3 X=1.2 X=1.1
0 21.300 65.680 90.400 123.700 169.960 237.500
10 16.768 58.584 82.846 116.025 163.015 233.249
20 12.534 50.641 74.247 107.139 154.795 228.092
30 8.923 41.770 64.461 96.798 144.953 221.708
40 6.091 31.938 53.316 84.699 133.042 213.585 X t
an
(s)
50 4.023 21.435 40.632 70.460 118.418 203.028 1.1 729
60 2.540 11.925 26.420 53.609 100.127 188.753 1.2 381
70 1.437 5.650 12.725 33.714 76.841 168.506 1.3 237
80 0.638 2.410 4.605 12.943 46.698 137.624 1.4 155
90 0.202 0.673 1.290 2.842 11.433 85.548 1.5 103
94 0.142 0.474 0.748 1.265 4.192 53.870 1.8 24
98 0.083 0.276 0.435 0.736 2.017 20.682
100 0.053 0.177 0.279 0.472 0.930 4.088 t
ab
(s) = 840
6RA7078-6DS22 280A/1Q 400V
6RA7078-6FS22 280A/1Q 460V
6RA7078-6DV62 280A/4Q 400V
6RA7078-6FV62 280A/4Q 460V
0,1
1,0
10,0
100,0
1000,0
0
10 20 30 40 50 60 70 80 90 94 98
100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
6RA7078-6DS22 280A/1Q 400V
6RA7078-6FS22 280A/1Q 460V
6RA7078-6DV62 280A/4Q 400V
6RA7078-6FV62 280A/4Q 460V
0
50
100
150
200
250
300
0 1020304050607080909498100
Base-load current as % of rated DC current
Overload period in s with cycle time of 300s
X=1,8
X=1,5
X=1,4
X=1,3
X=1,2
X=1,1
