05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-9
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
r012
(G185)
Motor temperature
Display of motor temperature when a KTY 84 temperature sensor is
connected (P490.x=1).
A value of "0" is always output in r012 when a PTC thermistor or no
temperature sensor is installed.
i001: Motor temperature 1 (sensor at terminals 22 / 23)
i002: Motor temperature 2 (sensor at terminals 204 / 205)
-58 to +318
[°C]
1°C
Ind: 2
Type: I2
P052 = 3
r013 Heatsink temperature
Display of heatsink temperature
-47 to +200
[°C]
1°C
Ind: None
Type: I2
P052 = 3
r014 Temperature rise
i001: Calculated motor temperature rise (see P114)
i002: Calculated thyristor temperature rise (see P075)
0.0 to 200.0
[%]
0.1%
Ind: 2
Type: O2
P052 = 3
r015 Display of line voltage (armature)
(generated as arithmetic rectification average, RMS value display applies to
sinusoidal voltage, average over 3 line-to-line voltages)
0.0 to 2800.0
[V]
0.1V
Ind: None
Type: O2
P052 = 3
r016 Display of line voltage (field)
(generated as arithmetic rectification average, RMS value display applies to
sinusoidal voltage)
0.0 to 800.0
[V]
0.1V
Ind: None
Type: O2
P052 = 3
r017 Display of line frequency
0.00 to 120.00
[Hz]
0.01Hz
Ind: None
Type: O2
P052 = 3
r018
(G163)
Display of firing angle (armature)
0.00 to 180.00
[degrees]
0.01degrees
Ind: None
Type: O2
P052 = 3
r019
(G162)
Display of actual armature current
The internal actual armature current value is displayed (arithmetic average
over the last 6 current peaks in each case)
-400.0 to 400.0
[% of P100]
0.1% of P100
Ind: None
Type: I2
P052 = 3
r020
(G162)
Display of the absolute value of armature current setpoint
0.0 to 300.0
[% of P100]
0.1% of P100
Ind: None
Type: I2
P052 = 3
r021
(G160)
Display of torque setpoint after torque limitation
Steps: 1
=
∧
0.1% of rated motor torque (=rated motor armature current
(P100) * magnetic flux at rated motor field current (P102))
-400.0 to 400.0
[%]
0.1% (see column on
left)
Ind: None
Type: I2
P052 = 3
r022
(G160)
Display of torque setpoint before torque limitation
Steps: 1
=
∧
0.1% of rated motor torque (=rated motor armature current
(P100) * magnetic flux at rated motor field current (P102))
-400.0 to 400.0
[%]
0.1% (see column on
left)
Ind: None
Type: I2
P052 = 3
r023
(G152)
Display of speed controller setpoint/actual value deviation
-200.00 to 199.99
[%]
0.01%
Ind: None
Type: I2
P052 = 3
r024
(G145)
Display of actual speed value from pulse encoder
-200.00 to 199.99
[%]
0.01%
Ind: None
Type: I2
P052 = 3
r025
(G151)
Display of actual speed controller value
-200.0 to 199.99
[%]
0.01%
Ind: None
Type: I2
P052 = 3
r026
(G152)
Display of speed controller setpoint
-200.0 to 199.99
[%]
0.01%
Ind: None
Type: I2
P052 = 3
r027
(G136)
Display of ramp-function generator output
-200.00 to 199.99
[%]
0.01%
Ind: None
Type: I2
P052 = 3
r028
(G136)
Display of ramp-function generator input
-200.00 to 199.99
[%]
0.01%
Ind: None
Type: I2
P052 = 3
r029
(G135)
Display of main setpoint before limitation
-200.00 to 199.99
[%]
0.01%
Ind: None
Type: I2
P052 = 3
r034
(G166)
Display of firing angle (field)
0.00 to 180.00
[degrees]
0.01degrees
Ind: None
Type: O2
P052 = 3
r035
(G166)
Display of field current controller actual value
0.0 to 199.9
[% of P102]
0.1% of P102
Ind: None
Type: O2
P052 = 3
