05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-13
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
P055
*
(G175)
Copy function data set
This parameter allows parameter set 1, 2, 3 or 4 to be copied
to parameter
set 1, 2, 3 or 4. This function is applicable only to parameters with 4 indices
in the function data set (see also Section 9.1, Data sets and Section 9.11,
and Section 8, Sheet G175).
0xy Do nothing
, automatic resetting value at the end of a copy
operation.
1xy The contents of parameter set x (source data set, x=1, 2, 3 or 4)
are copied
to parameter set y (target data set, y=1, 2, 3 or 4)
(parameter set x remains unchanged, the original contents of
parameter set y are overwritten).
x and y are the respective parameter set numbers (1, 2, 3 or 4)
of the source and target parameter sets.
The copy operation is started by switching P055 over into parameter mode
when P055=1xy.
During the copy operation, the numbers of the parameters being copied are
displayed on the operator panel (PMU).
At the end of the copy operation, P055 is reset to P055=0xy.
011 to 143
1
Ind: None
FS=012
Type: L2
P052 = 3
P051 = 40
Offline
r056
(G175)
Display of active function data set
1 to 4
1
Ind: None
Type: O2
P052 = 3
P057
*
(G175)
Copy Bico data set
This parameter allows parameter set 1 or 2 to be copied
to parameter set 1
or 2. This function is applicable only to parameters with 2 indices in the Bico
data set (see also Section 9.1, Data sets and Section 9.11, and Section 8,
Sheet G175).
0xy Do nothing
, automatic resetting value at the end of a copy
operation.
1xy The contents of parameter set x (source data set, x=1 or 2) are
copied
to parameter set y (target data set, y=1 or 2) (parameter
set x remains unchanged, the original contents of parameter set
y are overwritten).
x and y are the respective parameter set numbers (1 or 2) of the
source and target parameter sets.
The copy operation is started by switching P057 over into parameter mode
when P057=1xy.
During the copy operation, the numbers of the parameters being copied are
displayed on the operator panel (PMU).
At the end of the copy operation, P057 is reset to P057=0xy.
011 to 121
1
Ind: None
FS=012
Type: L2
P052 = 3
P051 = 40
Offline
r058
(G175)
Display of active Bico data set
1 to 2
1
Ind: None
Type: O2
P052 = 3
r059 Display of operating state
Meaning as for r000
0.0 to 14.5
0.1
Ind: None
Type: O2
P052 = 3
11.4 Definition of SIMOREG DC MASTER converter
r060
(G101)
Software version
Converter software release
i001: CUD
i002: Slot D (board location 2)
i003: Slot E (board location 2)
i004: Slot F (board location 3)
i005: Slot G (board location 3)
0.0 to 9.9
0.1
Ind: 5
Type: O2
P052 = 3
r061
(G101)
Creation date of software
i001: Year
i002: Month
i003: Day
i004: Hour
i005: Minute
Ind: 5
Type: O2
P052 = 3
r062
(G101)
Checksum
i001: Converter firmware checksum
i002: Boot sector checksum
Ind: 2
Type: L2
P052 = 3
