05.05 Parameter list
SIEMENS AG 6RX1700-0AD76 11-15
SIMOREG DC Master Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
11.5 Definition of SIMOREG DC MASTER power section
P067
*
(G101)
Load class [SW1.8 and later]
1 Load class DC I
2 Load class DC II
3 Load class DC III
4 Load class DC IV
5 US rating
The load classes are described in Chapter 3.4.1.
Depending on the load class selected, the device rated DC of the
SIMOREG DC Master is reduced to a value of different magnitude to suit
the power section and load class.
The current value of the device rated DC is indicated in parameter r072.002.
Notes:
If the device rated DC is reduced via parameter P076.001, the lesser of the
two values is active.
If you set a value of > 1 in P067, you must ensure that the "Dynamic
overload capability of power module“ is enabled, i.e. a value of > 0 must be
set in parameter P075.
The SIMOREG DC Master does not
monitor for compliance with the criteria
of the load class set in parameter P067. If permitted by the power module,
the unit can operate for overload periods in excess of those defined by the
load class. The permissible overload period for the installed power module
is always longer than the period defined for the load class. The SIMOREG
DC Master does monitor
the actual permissible overload period for the
power module. See Section 9.15.
1 to 5
1
Ind: None
FS=1
Type: O2
P052 = 3
P051 = 40
Offline
r068
(G101)
Options according to rating plate
0 No option
1 Option L04 (low voltage, 85V)
2 Option K00 (terminal expansion)
3 L04 and K00
Ind: None
Type: 02
P052 = 3
r069
(G101)
Serial number of SIMOREG DC Master converter
i001: 1
st
and 2
nd
places of serial number
i002: 3
rd
and 4
th
places of serial number
i003: 5
th
and 6
th
places of serial number
i004: 7
th
and 8
th
places of serial number
i005: 9
th
and 10
th
places of serial number
i006: 11
th
and 12
th
places of serial number
i007: 13
th
and 14
th
places of serial number
i008 to i015: 0
i016: Checksum for serial number
The serial number ASCII code is displayed in this parameter. The number is
output in plaintext on the OP1S panel.
Ind: 16
Type: L2
P052 = 3
r070
(G101)
MLFB (order number) of SIMOREG DC Master converter
The corresponding MLFB is displayed in encoded form in this parameter.
The MLFB is displayed in plaintext on the OP1S panel.
0 to 120
1
Ind: None
Type: O2
P052 = 3
r071
(G101)
Converter rated supply voltage (armature)
Converter rated supply voltage (armature) as specified on rating plate
10 to 1000
[V]
1V
Ind: None
Type: O2
P052 = 3
r072
(G101)
Converter rated DC current (armature)
i001: Converter rated DC current (armature) as specified on rating
plate (output DC current at power terminals 1C1 and 1D1)
i002: Actual converter rated DC current (armature) according to
setting in parameter P076.001 or P067
0.0 to 6553.5
[A]
0.1A
Ind: 2
Type: O2
P052 = 3
r073
(G101)
Converter rated DC current (field)
i001: Converter rated DC current (field) as specified on rating plate
(output DC current at power terminals 3C and 3D)
i002: Actual converter rated DC current (field) as set in parameter
P076.002
0.00 to 100.00
[A]
0.01A
Ind: 2
Type: O2
P052 = 3
