Parameter list 05.05
11-72 SIEMENS AG 6RX1700-0AD76
SIMOREG DC Master Operating Instructions
PNU Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
P662
*
BDS
(G180)
Source for control word 1, bit4
(0=set ramp-function generator to zero, 1=enable ramp-function generator)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P663
*
BDS
(G180)
Source for control word 1, bit5
(0=ramp-function generator stop, 1=ramp-function generator start)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P664
*
BDS
(G180)
Source for control word 1, bit6
(0=enable setpoint, 1=disable setpoint)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P665
*
BDS
(G180)
1st source for control word 1, bit7
(0
→1 transition=acknowledge; ORed with 2
nd
and 3
rd
sources for bit7)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P666
*
BDS
(G180)
2nd source for control word 1, bit7
(0
→1 transition=acknowledge; ORed with 1
st
and 3
rd
sources for bit7)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P667
*
BDS
(G180)
3rd source for control word 1, bit7
(0
→1 transition=acknowledge; ORed with 1
st
and 2
nd
sources for bit7)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P668
*
BDS
(G180)
Source for control word 1, bit8
(1=inching bit0)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P669
*
BDS
(G180)
Source for control word 1, bit9
(1=inching bit1)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P671
*
BDS
(G180)
Source for control word 1, bit11
(0=pos. direction of rotation disabled, 1=pos. direction of rotation enabled)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P672
*
BDS
(G180)
Source for control word 1, bit12
(0= neg. direction of rotation disabled, 1= neg. direction of rotation enabled)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
P673
*
BDS
(G180)
Source for control word 1, bit13
(1=raise motorized potentiometer)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P674
*
BDS
(G180)
Source for control word 1, bit14
(1=lower motorized potentiometer)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P675
*
BDS
(G180)
Source for control word 1, bit15
(0=external fault, 1=no external fault)
All binector numbers
1
Ind: 2
FS=1
Type: L2
P052 = 3
P051 = 40
Offline
Control word 2
P676
*
BDS
(G181)
Source for control word 2, bit16
(select function data set bit 0)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P677
*
BDS
(G181)
Source for control word 2, bit17
(select function data set bit 1)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P680
*
BDS
(G181)
Source for control word 2, bit20
(select fixed setpoint 0)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
P681
*
BDS
(G181)
Source for control word 2, bit21
(select fixed setpoint 1)
All binector numbers
1
Ind: 2
FS=0
Type: L2
P052 = 3
P051 = 40
Offline
